Specifications

Chassis:Cinder and Igniter up to 450hp
Inferno up to 605 hp
Ultra up to 500hp
Body:Extruded aluminum – available with quint or pumper body styles
Compartments:Quint 1: Left side full height x 24” deep; Right side full height w/EZ-Stack hose bed
Quint 2: Left and right side full height 24” deep lower/12” deep upper w/hose chutes
MVP Rescue Ladder: 6 compts left, 4 compts right plus EZ-Stack hose bed
Truck: Left and right side full height, 24” deep lower/transverse upper ahead of aerial
Ladder Storage:150’ to 156’ ground ladders enclosed in full length torque box
Pump:Up to 3000 gpm pump
Tank Size:Up to 750 gallons on single axle or 1000 gallons on tandem
Ladder and Reach:2-section heavy duty rear mount aerial with -6° to +72° operational envelope
Over 180° rotation at -6°
57’ vertical reach at 72° and 52’ horizontal reach at 0°
34’ vertical and 42’ horizontal reach at 30°
Rated Load Capacity:500 pounds flowing 1250 GPM
Up to 1250 pounds distributed + 500 pounds at the tip while flowing 1250 GPM
No restrictions on aerial or monitor movement or placement while flowing 1250 GPM
Warranty:10 year cab and body structural
25 year aerial structural
10 year waterway and waterway seals
15 year torque box & stabilizer
2 year mechanical, chassis, cab, body and aerial
